DC FANS
180x180x65 mm
PRODUCT SPECIFICATIONS
Frame: Aluminum
Impeller: Glass-Fiber-Reinforced Plastic, UL94V-0
Ambient Temperature Range: -10°C ~ +70°C
Bearing: Sleeve Bearing or Ball Bearing
Motor Structure: Brushless DC Motor
Termination: Lead Wire, 300 ± 10 mm
Weight: 1,450 g
Typical Applications
Industrial Automation
Communication Equipment
Power Supplies
Electronic Cooling
TECHNICAL DATA
Performance Specifications
| Model | Voltage (VDC) |
Operating Voltage (VDC) |
Current (A) |
Power (W) |
Speed (RPM) |
Airflow (CFM) |
Pressure (in-H2O) |
Noise (dB) |
|---|---|---|---|---|---|---|---|---|
| HYD121865LBL | 12 | 10.0 – 14.0 | 0.45 | 5.5 | 1500 | 215 | 0.42 | 36 |
| HYD121865MBL | 12 | 10.0 – 14.0 | 1.10 | 13.2 | 2200 | 300 | 0.58 | 46 |
| HYD121865HBL | 12 | 9.0 – 13.8 | 1.90 | 23 | 2800 | 375 | 0.70 | 53 |
| HYD121865XBL | 12 | 9.0 – 13.8 | 4.20 | 50.4 | 3400 | 460 | 1.10 | 63 |
| HYD121865UBL | 12 | 9.0 – 13.8 | 5.40 | 64.8 | 3700 | 490 | 1.25 | 68 |
| HYD241865LBL | 24 | 15.0 – 28.0 | 0.20 | 5 | 1500 | 215 | 0.42 | 36 |
| HYD241865MBL | 24 | 12.0 – 28.0 | 0.52 | 13 | 2200 | 300 | 0.58 | 46 |
| HYD241865HBL | 24 | 12.0 – 27.6 | 0.97 | 24 | 2800 | 375 | 0.70 | 53 |
| HYD241865XBL | 24 | 12.0 – 27.6 | 2.10 | 50.4 | 3500 | 470 | 1.20 | 65 |
| HYD241865UBL | 24 | 12.0 – 27.6 | 2.65 | 63.6 | 3800 | 500 | 1.30 | 69 |
| HYD481865LBL | 48 | 30.0 – 63.0 | 0.12 | 5.8 | 1500 | 215 | 0.42 | 36 |
| HYD481865MBL | 48 | 28.0 – 60.0 | 0.30 | 14.5 | 2200 | 300 | 0.58 | 46 |
| HYD481865HBL | 48 | 24.0 – 55.0 | 0.48 | 23.5 | 2800 | 375 | 0.70 | 53 |
| HYD481865XBL | 48 | 24.0 – 55.0 | 1.03 | 49.4 | 3500 | 470 | 1.20 | 65 |
| HYD481865UBL | 48 | 24.0 – 55.0 | 1.30 | 62.4 | 3800 | 500 | 1.30 | 69 |
