AC AXIAL FANS
ø200 mm
PRODUCT SPECIFICATIONS
Material: Steel
Typical Applications
HVAC Systems
Industrial Ventilation
Machinery Cooling
Equipment Ventilation
TECHNICAL DATA
Performance Specifications
| Model | Voltage (V) |
Freq. (Hz) |
Current (A) |
Power (W) |
Speed (RPM) |
Airflow (m³/hr) |
Noise (dB) |
Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| 2E200Z | 230 | 50/60 | 0.39/0.45 | 80/95 | 2700/3200 | 870/1000 | 60/65 | 1.9 |
| 2D200Z | 380 | 50/60 | 0.13/0.15 | 70/90 | 2650/3000 | 870/1000 | 60/64 | 1.9 |
| 4E200Z | 230 | 50/60 | 0.15/0.18 | 29/38 | 1420/1600 | 450/560 | 48/51 | 1.9 |
| 4D200Z | 380 | 50/60 | 0.12 | 50/90 | 1450/1750 | 450/530 | 48/53 | 1.9 |
